Basic programming examples using the NJ2DG repeater modules.

440 MHz (441.650) Single Band Operation

URCALL = cqcqcq

RPT1 = NJ2DG B The B must be in the 8th character position

RPT2 = blank

MYCALL = your callsign

2 Meters (145.140) Single Band Operation

URCALL=cqcqcq

RPT1 = NJ2DG C The C must be in the 8th character position

RPT2 = blank

MYCALL = your callsign

1.2 GHz to 440 MHz Crossband Example

URCALL = cqcqcq

RPT1 = NJ2DG A The B must be in the 8th character position

RPT2 = NJ2DG B The A must be in the 8th character position

MYCALL = your callsign

440 MHz to 2 Meters Crossband Example

URCALL = cqcqcq

RPT1 = NJ2DG B The B must be in the 8th character position

RPT2 = NJ2DG C The C must be in the 8th character position

MYCALL = your callsign

2 Meters to 440 MHz Crossband Example

URCALL = cqcqcq

RPT1 = NJ2DG C The C must be in the 8th character position

RPT2 = NJ2DG B The B must be in the 8th character position

MYCALL = your callsign

NJ2DG Central Jersey Digital Group

1.2 GHz (1284.000) Single Band Operation Example

URCALL= cqcqcq

RPT1 = NJ2DG A The A must be in the 8th character position

RPT2 = blank

MYCALL = your callsign

Basic Programming

440 MHZ and the Gateway>>>>Your Callsign Logged to Last Heard List

URCALL = cqcqcq

RPT1 = NJ2DG B The B must be in the 8th character position

RPT2 = NJ2DG G The G must be in the 8th character position

MYCALL = your callsign

Dplus Functions

The NJ2DG system currently has Dplus functionality in place. We currently have the D-Echo application running on the gateway computer. D-Echo on will echo back your anything you transmit on a band so you can hear yourself and the signal quality at a given location.

.

D-Echo on 1.2 GHz (1284.000)

URCALL = NJ2DG E The E (Echo) must be in the 8th character position

RPT1     = NJ2DG A The A (1.2 GHz Repeater) must be in the 8th character position

RPT2     = NJ2DG G The G (Gateway) must be in the 8th character position

MYCALL = your call sign

D-Echo on 440 MHz (441.650)

URCALL = NJ2DG E The E (Echo) must be in the 8th character position

RPT1      = NJ2DG B The B (440 Repeater) must be in the 8th character position

RPT2      = NJ2DG G The G (Gateway) must be in the 8th character position

MYCALL = your call sign

D-Echo on 2M (145.140)

URCALL = NJ2DG E The E (Echo) must be in the 8th character position

RPT1      = NJ2DG C The C (2 Meter Repeater) must be in the 8th character position

RPT2      = NJ2DG G The G (Gateway) must be in the 8th character position

MYCALL = your call sign
