NJ2DG Central Jersey Digital Group
The NJ2DG Repeater System has G2 Gateway Access. All users accessing onto the new G2 gateway system nationally will need to register ONLY ONCE. If you choose, you can complete your initial G2 registration through the following link: https://rpt.nj2dg.org/Dstar.org
Once receiving an email confirmation confirming your registration then you must sign back in through the above link and you must complete the following steps after clicking the Personal Information tab
Each user must set the first line (# 1 of 8) to be able to use the Gateway.
1) Check the box next to number 1 to enable editing for the line
2) Put a SPACE in the box under "Initial"
3) Do NOT check the RPT box
4) Type your call sign in the pcname box in lower case
5) Click the Update button
You have now successfully completed the G2 gateway registration process. Questions(?)
-
Some systems listed as G2 gateways on https://rpt.nj2dg.org/Dstar.org webpage under GW Information tab may not be fully connected to a repeater system.
Programming by use the of the D-
D-
NJ2DG B and C are connected, see who else is connected. http://ref020.dstargaterway.org
KI4SWY Callsign Query for Gateway Registered Callsigns This is small website interface that anybody can go to, and Query a callsign, and it will tell you which repeaters are they are registered on, and if they have any terminals registered: http://query.ki4swy.org
Gateway Programming
Programming Examples
Zone Call Example -
URCALL =/K5TIT B This URCALL entry indicates that you are calling to K5TIT 440 Repeater, please
note the leading character is the / followed by the repeater call with the module B in the 8th character position.
RPT1 = NJ2DG B The B (440 Repeater) must be in the 8th character position
RPT2 = NJ2DG G The G (Gateway) must be in the 8th character position
MYCALL = your call sign
Gateway Call to a Individual -
URCALL = K7FAY Finding where K7FAY was last heard and trust server will automatically route your
gateway call to the last module that K7FAY was heard on.
RPT1 = NJ2DG B The B (440 Repeater) must be in the 8th character position
RPT2 = NJ2DG G The G (Gateway) must be in the 8th character position
MYCALL = your call sign
Gateway Call to Linked Repeaters with D-
URCALL = CQCQCQ
RPT1 = NJ2DG B The B (440 Repeater) must be in the 8th character position
RPT2 = NJ2DG G The G (Gateway) must be in the 8th character position
MYCALL = your call sign
Hot Spot / Node Simplex or Repeater
URCALL = CQCQCQ
RPT1 = None
RPT2 = None
MYCALL = your call sign
